T100S-HP - high-power tunable laser

Most advanced and cost-effective solution for R&D and Manufacturing environments. Offers a signal to source spontaneous emission ratio higher than 90 dB.

All products T100S-HP - high-power tunable laser

Key features Applications Description Resources Related products

All products T100S-HP - high-power tunable laser

Key features Applications Description Resources Related products

Key features

Power ≥ +10 dBm for Essential models
Power ≥ +8 dBm for Extended Range models
Dynamic Range higher than 90 dB
Tuning range up to 200 nm
Wavelength accuracy < ± 20 pm
Sweeping & Stepping operations

Applications

Fiber optic transmission testing
Passive optical component testing
Optical amplifier testing
Thin film growth monitoring
Optical alignment
Fiber optic sensors
Spectroscopy
Interferometry
Photonic material characterization

Description

The complete portfolio of the T100S-HP features 6 tunable lasers to cover the entire wavelength range from 1240 to 1680 nm:

/O+ model: 1240-1380 nm
/O model: 1260-1360 nm
/ES model: 1350-1510 nm
/SCL model: 1440-1640 nm
/CL model: 1500-1630 nm
/CLU model: 1500-1680 nm

Drawing on the success of the trend-setting laser series TUNICS, the T100S-HP provides a combination of high power with low spontaneous emission:

The /O and /CL lasers have 10 dBm minimum output power and are dedicated to the main telecom applications.

The /O+, /ES, /SCL and /CLU lasers have 8 dBm minimum output power and the largest wavelength ranges available on the market, making it possible to cover the full telecom wavelength band from 1240 to 1680 nm at 8 dBm with just 3 lasers. This is done by combining the /O+, /ES and /CLU lasers.
