PPM1 - Service activation PON power meter

Versatile dual-layer tester purpose-built for PON service activation, with added broadband capabilities.

PON-aware technology

The PPM1 leverages a unique patented technology that makes all the difference in the field. The PPM1 automatically detects the PON technology in use and self-adjusts the pass/fail criteria, enabling rapid and error-free testing.

Next-gen PON service activation

A single power meter for 1G and 10G—No training required.

Next-generation passive optical networks (PONs) will, in most cases, leverage existing outdoor plant infrastructure. Adding new services on existing networks translates into overlaying multiple wavelengths on the same physical fiber plant. The PPM1 is compatible with multiple services including GPON, EPON, XGS-PON and 10G-EPON technologies. Its wavelength-selective design allows it to measure up to two downstream signals simultaneously, assessing power level for rapid and reliable service activation.

Purpose-built for service activation

Unique PON-aware™ capability: automatically detects PON technology in use
Supports 1G/10G PON networks: G/E-PON and XGS-PON/10G-EPON
No training required: highly intuitive interface and color touchscreen
Robust and rugged: IP54 design for dust and water protection
3-year warranty and calibration interval
Long-lasting LiPo battery (rechargeable and field-replaceable)
Broadband Power Meter mode and VFL port (PRO model)

Applications

Service activation: Multilayer FTTx PON
Service activation: GPON, EPON, XGS-PON and 10G EPON
Network troubleshooting

Share test results. Boost compliance. Unlock insights. 

Cloud-hosted solution for sharing test results and ensuring compliance.

Paired with EXFO’s leading test instruments, EXFO Exchange drives an entire ecosystem, while integrating seamlessly with existing operation processes.

Key benefits:


icon automate test results managementAutomate test results management.

icon boost compliance efficiencyBoost compliance and efficiency.

icon improve collaboration visibilityImprove collaboration and visibility.

icon access comprehensive reportingAccess comprehensive reporting.

icon unlock insights see what mattersUnlock insights to see what matters.
