| Wavelength (nm)(b) | 1310 ± 20/1550 ± 20/1625 ± 10/1650 ± 5 |
| Live wavelength (nm) | 1650 nm: bandpass 1650 nm ± 7 nm Isolation >50 dB out of 1650 nm ± 10 nm |
| Dynamic range (dB)(c) | 45/44/42/42 |
| Event dead zone (m)(d) | 0.5 |
| Attenuation dead zone (m)(d) | 2.0 |
| PON dead zone (m)(e) | 25 |
| Distance range (km) | 0.1 to 400 |
| Pulse width (ns) | 3 to 20 000 |
| Linearity (dB/dB) | ±0.03 |
| Loss threshold (dB) | 0.01 |
| Loss resolution (dB) | 0.001 |
| Sampling resolution (m) | 0.04 to 10 |
| Sampling points | Up to 256 000 |
| Distance uncertainty (m)(f) | ±(0.75 + 0.0025 % × distance + sampling resolution) |
| Measurement time | User-defined |
| Reflectance accuracy (dB)(b) | ±2 |
| Typical real-time refresh (Hz) | 4 |
| Note: All specifications valid at 23 °C ± 2 °C with an FC/APC connector, unless otherwise specified. (b) Typical. (c) Typical dynamic range with longest pulse and three-minute averaging at SNR = 1. (d) Typical, for reflectance at –55 dB, using a 3-ns pulse. Attenuation dead zone at 1310 nm is 2.5 m (typical) with reflectance below –45 dB. (e) Non-reflective FUT, non-reflective splitter, 13-dB loss, 50-ns pulse, typical value at 1550 nm. (f) Does not include uncertainty due to fiber index. | |
| Display | 8-inch (203 mm), 1280×800, color touchscreen (viewable in sunlight) |
| Interfaces | USB-A ports (2) USB-C port with power delivery RJ45 LAN 10/100/1000 Mbit/s |
| RF comms(a)(b) | Bluetooth, Wi-Fi, 2G/3G/4G LTE, GNSS (GPS/GALILEO/QZSS) |
| Storage | >20,000 OTDR SOR traces |
| Battery | Rechargeable LiFePO4 battery, up to 10 hours(c) of operation as per Telcordia (Bellcore) GR-196-CORE |
| Power supply | Input: AC/DC adapter, 100 to 240 V AC, 50 to 60 Hz, 1.5 A max. Output: 5 to 20 V DC, 3.0 A max., 45 W max., USB-C power delivery standard supported |
| Weight (including battery and module) | 2.4 kg (5.3 lb) |
| Size (H × W × D) | 198 mm × 249 mm × 71 mm (7.8 in × 9.8 in × 2.8 in) |
| Temperature | Operating: –10 °C to 50 °C (14 °F to 122 °F) Storage: –40 °C to 70 °C (–40 °F to 158 °F) |
| Relative humidity | 0 % to 95 % non-condensing |
| Warranty (year) | 1 |
| (a) Free 36-month basic data plan provided. (b) Restrictions may apply depending on country/region which will prevent EXFO from providing mobile connectivity. Contact EXFO for details. (c) Battery life varies significantly based on device configuration, usage, network and feature configuration, signal strength, settings and other factors. | |
