FLS-240 Pocket Pal - FLS-240 - 可视故障定位仪

简单直接的解决方案，用于识别断裂、弯曲、故障连接器、熔接以及导致信号损耗的其它原因。

规格书用户手册

主要优点

故障检测距离最高可达5 km

635 nm的明亮红色激光

脉冲和CW运行时间长达50小时（典型值）

用于2.5 mm或1.25 mm插针的通用连接器

应用

断裂和弯曲定位

光纤识别

规格

技术规格
Auto-Wavelength Switching
Calibrated wavelengths	635
Fiber Connector Type	Universal 1.25/Universal 2.5
Fiber Type	VFL
Product type	Handheld
Test Type	Fiber continuity/Fiber tracing/Visual fault location
Visual Fault Locator (VFL)

规格书

描述

The FLS-240 Pocket Pal Visual Fault Locator is a straightforward solution for identifying breaks, bends, faulty connectors or splices, as well as other causes of signal loss. It can detect faults over distances of up to 5 km. The FLS-240 visually locates faults by creating a bright red glow at the exact location of the fault on singlemode or multimode fibers.

Robust design

To ensure ruggedness, the Pocket Pal features rubber seals, a fully enclosed laser head and a long-lasting On/Off switch. It has been tested to provide reliable operation under intensive use and harsh conditions.
